MK5159 IFM Cable Connector T Slot Cylinder Sensor MKT3020BBPKG A 0 3M ZH ASR

Ask Lasest Price
Brand Name :	IFM
Model Number :	MK5159
Certification :	CE
Price :	USD
Payment Terms :	L/C, T/T
Supply Ability :	100
Delivery Time :	10-12Days

Add to Cart

Product Details
Company Profile

MK5159 IFM Cable Connector T Slot Cylinder Sensor MKT3020BBPKG A 0 3M ZH ASR

IFM T-slot cylinder sensor MK5159 MKT3020BBPKG/A/0,3M/ZH/ASR

The IFM MK5159 MKT3020BBPKG/A/0,3M/ZH/ASR is a T-slot cylinder sensor, manufactured by IFM Electronic GmbH. Here's some information about the sensor:

1. Model: MK5159 MKT3020BBPKG/A/0,3M/ZH/ASR
2. Manufacturer: IFM Electronic GmbH
3. Function: The T-slot cylinder sensor is designed to detect the position of a cylinder's piston within a T-slot cylinder. It provides feedback on the extended or retracted state of the cylinder's piston.
4. Sensing Principle: The sensor uses a magnetic sensing principle to detect the position of a magnet embedded within the cylinder's piston. It can sense the magnetic field, indicating whether the piston is extended or retracted.
5. Sensing Range: The specific sensing range of the sensor depends on the model variant. Unfortunately, the provided model number does not contain information about the sensing range. It's recommended to refer to the product documentation or datasheet for the exact sensing range of this particular model.
6. Electrical Connection: The sensor supports a specific electrical connection type, indicated by the "/0,3M/ZH/ASR" in the model name. The exact type of electrical connection may vary, and you should consult the product documentation or datasheet for more details.
7. Housing Type: The sensor is likely designed to be mounted within the T-slot of a cylinder. It may have a compact and robust housing to withstand the operating conditions within the cylinder.

For detailed specifications, installation guidelines, and compatibility information for the IFM MK5159 MKT3020BBPKG/A/0,3M/ZH/ASR T-slot cylinder sensor, it is recommended to consult the official documentation provided by IFM Electronic GmbH or contact their technical support. They will be able to provide you with accurate and up-to-date information based on your specific requirements and the latest product information available.

Product characteristics

Electrical design	PNP
Output function	normally open
Dimensions [mm]	25.3 x 5 x 6.5

Electrical data

Operating voltage [V]	10...30 DC; ("supply class 2" to cULus)
Current consumption [mA]	< 10
Protection class	III
Reverse polarity protection	yes
Max. power-on delay time [ms]	30

Outputs

Electrical design	PNP
Output function	normally open
Max. voltage drop switching output DC [V]	2.5
Permanent current rating of switching output DC [mA]	100
Switching frequency DC [Hz]	6000
Short-circuit protection	yes
Type of short-circuit protection	pulsed
Overload protection	yes

Detection zone

Response sensitivity [mT]	2
Travel speed [m/s]	> 10

Accuracy / deviations

Hysteresis [mm]	1
Repeatability [mm]	< 0.2

Operating conditions

Ambient temperature [°C]	-25...85
Protection	IP 65; IP 67

Tests / approvals

EMC

EN 61000-4-2 ESD	- CD / 8 kV AD
EN 61000-4-3 HF radiated	10 V/m
EN 61000-4-4 Burst	2 kV
EN 61000-4-6 HF conducted	10 V
EN 55011	class B

MTTF [years]

2064

UL approval

MK5159 IFM Cable Connector T Slot Cylinder Sensor MKT3020BBPKG A 0 3M ZH ASR
