    SIEMENS 6ES7138-4FR00-0AA0 SIMATIC DP, ELECTRONICS MODULE 1F-RO 24 V DC/AC 24..230V/5A, F. ET200S, 30 MM OVERALL WIDTH

    SIEMENS 6ES7138-4FR00-0AA0 SIMATIC DP, ELECTRONICS MODULE 1F-RO 24 V DC/AC 24..230V/5A, F. ET200S, 30 MM OVERALL WIDTH

    The **SIEMENS 6ES7138-4FR00-0AA0** is a **SIMATIC DP** electronic module designed for the **ET200S** system. This module is equipped with **1 fail-safe relay output (1F-RO)** that supports **24V DC** and **24-230V AC** with a current rating of **5A**. The module has an overall width of **30mm**.

    Key specifications of the 6ES7138-4FR00-0AA0 electronic module:

    - **Product Code:** 6ES7138-4FR00-0AA0
    - **Product Line:** SIMATIC DP
    - **Module Type:** Electronics Module for ET200S
    - **Output Type:** 1 Fail-safe Relay Output (1F-RO)
    - **Voltage (DC):** 24V
    - **Voltage (AC):** 24-230V
    - **Current Rating:** 5A
    - **Overall Width:** 30mm

    This electronic module for the ET200S system features a single fail-safe relay output capable of handling both 24V DC and 24-230V AC signals with a current rating of 5A. With a 30mm overall width, this module offers a compact solution for integrating fail-safe relay outputs into the industrial automation setup.

    Product
    Article Number6ES7138-4FR00-0AA0
    Product Description*** Spare part *** SIMATIC DP, Electronics module 1F-RO 24 V DC/AC 24..230V/5A, f. ET200S, 30 mm overall width, 1 relay output (2 NO) Output current 5 A, load voltage 24 V DC and 24...230 V AC, Can be used up to Category 4 (EN 954-1)/ SIL3 (IEC61508)/PLE (ISO13849), if control takes place F-DO (e.g. 6ES7138-4FB02-0AB0) F-DQ
    Product familyNot available
    Product Lifecycle (PLM)PM410:Product cancellation
    PLM Effective DateProduct is cancelled since: 01.10.2023
    Notes
    This product is a spare part product. More information you'll get via "Alternative Buying Options".
    If you need assistance please contact our local Siemens office
    Price data
    Price GroupS20
    List Price Show prices
    Customer Price Show prices
    Surcharge for Raw Materialsee also metal factor (further details are available on the help page)
    Metal Factorsee also metal factor (further details are available on the help page)
    Delivery information
    Export Control RegulationsECCN : N / AL : N
    Estimated dispatch time (Working Days)1 Day(s)
    Net Weight (kg)0,107 Kg
    Packaging Dimension6,50 x 9,20 x 4,00
    Package size unit of measureCM
    Quantity Unit1 Piece
    Packaging Quantity1
    Additional Product Information
    EAN4025515074298
    UPC662643188134
    Commodity Code85389091
    LKZ_FDB/ CatalogIDST76
    Product Group4465
    Group CodeR152
    Country of originGermany
